Audi Prologue Concept 2014

Audi is launching into a new design era: At the Los Angeles Auto Show, Marc Lichte, Head of Design, is presenting the Audi prologue concept car. Lichte is giving the Audi brand a new styling direction in the large coupe.
Marc Lichte himself describes the character of the show car in this way: “Audi stands for sportiness, lightweight design and the quattro permanent all‑wheel drive. In the Audi prologue, we are expressing this know‑how in a new form – we have put the sportiest car in the luxury segment on wheels. Our team took new approaches in both exterior and interior design.”
The Audi Prologue concept technology combines power, comfort and efficiency. The 4.0 TFSI produces up to 445 kW (605 hp) of power and 750 Nm (553.2 lb‑ft) of torque; it accelerates the Audi prologue from 0 to 100 km/h (62.1 mph) in 3.7 seconds. Its dynamic all‑wheel steering, in which the rear wheels can turn up to five degrees, makes the large couple extremely responsive and stable while driving.

Audi Prologue Concept 2014 : exterior

The Audi prologue is somewhat shorter and flatter than today’s production A8* with a length of 5.10 meters (16.7 ft), wheelbase of 2.94 meters (9.6 ft), width of 1.95 meters (6.4 ft) and height of 1.39 meters (4.6 ft). A dominant feature at its low front end is a Singleframe displaying the four rings that is integrated into the automobile architecture. The large radiator grille has been widened much more, and it is positioned lower than on today’s production models. Its strong horizontal effect expresses an image of powerful dynamics. The cross bars have a finely structured diamond pattern, and their ends are split.

Audi Prologue Concept 2014 : Edges above the wheel arches refer back to the Ur-quattro

A characteristic feature of the Audi prologue are the flared shoulders above the wheels, front and rear. Like the blisters of the original Audi Ur‑quattro of the 1980s, they visualize the quattro drive – but they are no longer just added on, rather they are worked into the flow of the base architecture. In a side view, the shoulders form two gentle arcs above the wheels, which break up the somewhat lower shoulder line between the wheels.
The fenders, doors and rear side panels show curved muscular surfaces. The lower door area has a low concave shape that runs upwards to the rear – a motif that links to the design theme of air inlets. The side sills are drawn inward; glossy black aprons form a continuation of the front spoiler. All lines and surfaces on the Audi prologue show car are logically interrelated, which is typical Audi

Audi Prologue Concept 2014 : Rear section drives the whole car forward

The rear section of the Audi prologue also breaks with conventions. It is angled in the driving direction and is reminiscent of the side and rear views of a luxurious yacht; the sickle-shaped seam between the side panel and the bumper emphasizes this dynamism. The edge of the trunk lid, which is executed as a discreet spoiler, picks up on the blister line coming from the side panel. Between the C‑pillars, the rear window has a concave inward curve – it closes off the passenger compartment while enabling convenient cargo loading with the separate trunk lid. The Audi prologue unites the positive aspects of a saloon with the aesthetic highlights of a coupe.

The unconventional design of the LED rear lights with their 3D glass gives the tail lights all of the benefits of the new design: the new, long tail lights run across the entire width of the car. At its termination point, the light illuminates the frame of the embossed 3D form. Fine lines in the 3D glass appear to hover in the middle of the light. The brake light is located deep inside the lighting unit. When braking, the bottom of the 3D imprint is also illuminated, which makes the light appear to move towards the observer. This configuration on different levels, and the alternation between 2D and 3D lighting functions lets the observer experience the tail lights in an entirely new dynamic way.

Audi Prologue Concept 2014 : interior and operating concept

The spacious interior of the Audi prologue is like a luxurious lounge. It is based on Gran Turismo design, and it enables both very sporty driving and relaxed touring. The interface visually adapts to the specific driving style. The interior marks the beginning of a new design era at Audi, in which the architecture merges with the operating concept to form one unit. The surfaces for displays and controls are innovatively integrated into the instrument panel and console of the center tunnel, and the infotainment system brings driver and passenger into dialog with one another.

When entering the vehicle, the four-seat coupe receives its passengers with polite hospitality. The “butler” – an innovative intelligent software program – identifies them based on their smartphones and adjusts the seats and climate control system according to their preferences. The system also makes recommendations for music and route planning that are oriented towards the owner’s preferences. The Easy Slot system, an advanced development of the Audi phone box, is located under lids in the center console. A special mechanism networks the smartphones of passengers to the vehicle infotainment system and charges them.

Audi Prologue Concept 2014 : Entire front of instrument panel becomes a display

The new type of front passenger display enables digital interaction between the driver and front passenger for the first time. A wiping movement by the passenger is all it takes to send pre‑configured routes to the driver’s display and input them into the Audi virtual cockpit future.
On the console of the center tunnel, there is a fourth flexible touch display that is ergonomically adapted to the driver; it is used for climate control, handwriting input and other vehicle settings. This display consists primarily of an extremely thin, bendable OLED film (OLED: organic light emitting diodes), and it displays extremely sharp images that are rich in contrast. When not in use, the OLED display is integrated flush to the center console and is nearly invisible. When the car is started, the flexible display stands up. The fact that it bends ensures a constant distance to the hand which makes for better ergonomics. When operating the display, the wrist rests on the low-positioned gear selector lever of the eight-speed tiptronic.
Designers have also redesigned the shift-by-wire lever. It is now integrated seamlessly into the center console. Cupholders and smartphone slots are installed under lids on the center console, to the left and right of the console support element.

Audi Prologue Concept 2014 : virtual cockpit future shows images on three levels

The Audi virtual cockpit future offers a glimpse into the future of the digital cockpit: High-resolution displays and three mirrors generate a virtual stage on three levels – a fascinating view with visual depth. In the navigation view, the first level presents information that is important for driving; levels two and three generate the depth effect in the cockpit. Structuring the information on different levels makes it better organized and easier for the driver to comprehend. The content and colors of the Audi virtual cockpit future change as a function of driving style – in sporty driving, the display switches over to Sport mode with special presentation of the relevant information such as engine rpm, temperatures and charge pressure.

Inside the Audi prologue, every detail clearly illustrates its exclusive character. A finely crafted perforated panel covers the air vents. If the driver sets the blower to a higher stage, the panel retracts downwards.

Audi Prologue Concept 2014 : Sporty yet convenient

The technology of the Audi prologue is as sophisticated as its interior is emotion-evoking. The 4.0 TFSI, which is installed in the engine compartment like a technical masterpiece, produces 445 kW (605 hp) and 700 Nm (516.3 lb‑ft) of torque; in overboost mode, which the driver can call up for around 15 seconds, a boosted torque of 750 Nm (553.2 lb‑ft) is available. The sonorous biturbo V8 accelerates the two‑door coupe, which has an unladen weight of 1,980 kilograms (4,365.2 lb) from 0 to 100 km/h (62.1 mph) in 3.7 seconds.
The show car’s combined fuel consumption is just 8.6 liters per 100 kilometers (27.4 US mpg), which equates to CO2 emissions of 199 grams per kilometer (320.3 g/mile). One contributor to this high efficiency is a new 48‑volt subsystem of the vehicle electrical system – this is a technology that will soon be introduced to production cars at Audi. The 48‑volt system is supplied by a powerful belt starter generator, which turns the powertrain into a mild hybrid and has an energy recovery output of up to 12 kW during braking. An eight‑speed tiptronic directs engine power to the quattro permanent all-wheel drive, which works closely with torque vectoring.

Audi Prologue Concept 2014 : New five-link wheel suspensions

In the chassis, the adaptive air suspension sport – an air suspension with controlled damping – offers a large adjustment range between smooth rolling and very tight handling; it also varies the show car’s ground clearance over several levels. The front and rear suspensions are engineered as lightweight five-link designs. The large carbon-fiber ceramic brake discs decelerate the show car powerfully. On the 20‑inch front brakes, they are gripped by six-piston fixed calipers.

A technology highlight of the Audi prologue is its dynamic all-wheel steering – it boosts driving dynamics and ride comfort by an intelligent combination of dynamic and all-wheel steering. The driver therefore can enjoy an automobile with extremely good handling. In the lower speed range, this is made evident by better agility and turning ability. In the higher speed range, developers improved the car’s responsiveness which leads to greater vehicle stability. Overall, dynamic all-wheel steering – with rear wheel steering angles of up to five degrees – makes it easy to maneuver when parking and offers precise and sporty steering on country roads and impressively comfortable steering on freeways.
